Vibrating feeder
Safe and clean transportation of chips & co.
The KÖBO ECO>PROCESS vibrating feeders are used when bulk materials have to be transferred in metered quantities. If these are installed upstream of a chip centrifuge, a uniform chip flow is achieved. Different fractions can be screened through the use of sieve trays. The design of the vibrating feeders is customized.
Metal processing
◆
Machining
◆
Recycling
◆
Bulk material handling
◆
Filter technology
Design
Structure
A vibrating conveyor trough consists of a rectangular trough construction with an inclined base plate. Unbalance motors are attached to the two long sides of the trough construction. The unbalance motors generate a vibration that moves the material in the chute and transports it to the discharge. The movement of the conveyed material can be adjusted by setting the unbalance motors.
Typical use cases
➔
Transport of: fine and short chips, broken chips, long and clumped chips, grinding swarf and grinding sludge
➔
Targeted dosing of chips (e.g. for centrifuges)
➔
Optional: Screening of coarse/foreign particles and separation of tufts and small chips
Functionality
➔
Material transport by means of oscillating movements
➔
an elastically mounted, vibration-resistant conveyor trough is set into linear vibration
➔
the delivery speed and thus the delivery rate can be adjusted via the amplitude or oscillation frequency
➔
The excitation of the vibrating trough is carried out by electric motor vibration drives
Details
Customer benefits
➔
Individual adaptation of the construction to the structural conditions
➔
Precise material dosing
➔
Easy and quick to clean
➔
Low-maintenance continuous operation
➔
Efficient operation
